槽钢参数大全

型号 尺寸/mm 截面面积/em2 理论质量/(kg/m) 参考数值 h b d t r r1 X-X y-y Y1-Y1 zo/cm Wx/cm3 1x/cm4 ix/cm Wy/cm3 Iy/cm4 iy/cm Iy/cm4 5 50 37 4.5 7.0 7.0 3.5 6.928 5.438 10.4 26.0 1.94 3.55 8.3 1.10 20.9 1.35 6.3 63 40 4.8 7.5 7.5 3.8 8.451 6.634 16.1 50.8 2.45 4.50 11.9 1.19 28.4 1.36 8 80 43 5.0 8.0 8.0 4.0 10.248 8.045 25.3 101 3.15 5.79 16.6 1.27 37.4 1.43 10 100 48 5.3 8.5 8.5 4.2 12.748 10.007 39.7 198 3.95 7.80 25.6 1.41 54.9 1.52 12.6 126 53 5.5 9.0 9.0 4.5 15.692 12.318 62.1 391 4.95 10.2 38.0 1.57 77.1 1.59 14a 140 58 6.0 9.5 9.5 4.8 18.516 14.535 80.5 564 5.52 13.0 53.2 1.70 107 1.71 14b 140 60 8.0 9.5 9.5 4.8 21.316 16.733 87.1 609 5.35 14.1 61.1 1.69 121 1.67 16a 160 63 6.5 10.0 10.0 5.0 21.962 17.240 108 866 6.28 16.3 73.3 1.83 144 1_80 16 160 65 8.5 10.0 10.0 5.0 25.162 19.752 117 935 6.10 17.6 83.4 1.82 161 1.75 18a 180 68 7.0 10.5 10.5 5.2 25.699 20.174 141 1270 7.04 20.0 98.6 1.96 190 1.88 18 180 70 9.0 10.5 10.5 5.2 29.299 23.000 152 1370 6.84 21.5 11 1.95 210 1.84 20a 200 73 7.0 11.0 11.0 5.5 28.837 22.637 178 1780 7.86 24.2 128 2.11 244 2.01 20 200 75 9.0 11.0 11.0 5.5 32.837 25.777 191 1910 7.64 25.9 144 2.09 268 1.95 22a 220 77 7.0 11.5 11.5 5.8 31.846 24.999 218 2390 8.67 28.2 158 2.23 298 2.10 型号 尺寸/mm 截面面积/em2 理论质量/(kg/m) 参考数值 h b d t r r1 X-X y-y Y1-Y1 zo/cm Wx/cm3 1x/cm4 ix/cm Wy/cm3 Iy/cm4 iy/cm Iy/cm4 22 220 79 9.0 11.5 11.5 5.8 36.246 28.453 234 2570 8.42 30.1 176 2.21 326 2.03 25a 250 78 7.0 12.0 12.0 6.0 34.917 27.410 270 3370 9.82 30.6 176 2.24 322 2.07 25b 250 80 9.0 12.0 12.0 6.0 39.917 31.335 282 3530 9.41 32.7 196 2.22 353 1.98 25c 250 82 11.0 12.0 12.0 6.0 44.917 35.260 295 3...
