PWM 整流器设计摘 要 煤炭、石油和天然气等化石燃料的迅速消耗,不仅引起了能源危机,还造成了以及环境污染日益加剧,由于电力的清洁,输送方便,在各国的国民工业发展中都占据着重要的地位,随着电力的广泛应用,越来越多的负载对用电的种类提出了要求,需要一定的电力变换设备。电力电子技术的飞速发展,整流器的应用领域也日益扩大。在电压平衡状态下,PWM整流器具有能量的双向流动,在用电和配电、各种工业场合领域占据了重要的地位。本文首先对PWM整流器系统进行了研究。在查阅大量国内外文献资料的基础上,对整流器及其控制器的国内外发展现状及研究趋势做了详细的研究,并对课题研究的意义有了更深入的认识。接下来对三相电压型整流器的拓扑结构、数学模型、整流器的控制技术进行了分析,并结合一定的平台对PWM整流器进行研究设计,对其控制方法运用MATLAB 仿真软件进行了仿真。然后对 FPGA 的发展历程、应用、分类、开发工具、语言等内容进行了介绍。最后对滞环控制算法进行了模块划分,将其划分为 PI 算法模块,限幅与指令电流生成模块,滞环比较模块,PWM 脉冲生成及死区保护模块,AD 控制及数据储存模块,并在 Quartus II 软件环境下,使用 VHDL 语言通过编程实现模块化设计。实践证明,设计的 PWM整流器和控制算法是可行的。关键词:能源,PWM 整流器,控制方法,MATLABiPWM RECTIFIER DESIGNABSTRACTThe rapid consumption of fossil fuels such as coal, oil and natural gas has not only caused an energy crisis, but also caused an increase in environmental pollution. Due to the clean and convenient transportation of electricity, it plays an important role in the development of national industries in various countries. With the widespread use of electricity, more and more loads place demands on the types of electricity used, and certain power conversion equipment is required. With the rapid development of power electronics technology, the application fields of rectifiers are also expanding. In the state of voltage balance, the PWM rectifier has a bidirectional flow of energy, and plays an important role in the field of electr...
