毕业设计说明书（论文）中文摘要毕业设计说明书（论文）外文摘要摘要：本文主要进行了 CJSJ-200 齿轮复合加工机床电气控制的设计。主要用的数控系统为西门子 828D 数控系统,利用此数控系统的紧凑型，简单好用，实现最佳表面质量和高速高精度的和谐统一来进行电气控制的设计。对于齿轮复合加工电气控制设计主要是通过设计系统 PLC 程序来控制整个系统的驱动，来直接控制机床的各个部件，各个动作准确可靠而且运动精度很高。另外对于齿轮复合加工的研究也是很有实际用途的，既减少了工序，又提高了效率和精度，未来复合加工机床的推广和应用也会越来越多。本课题主要先根据设计要求设计出电气控制原理图，结合数控系统和设计要求进行 PLC 程序设计，根据 PLC 梯形图的控制程序并且安装驱动系统，分析出系统调试过程中所会出现的问题，设置相关的参数以及综合调试，从而能够实现齿轮复合加工。关键词：西门子 828D PLC 程序设计 齿轮复合加工Title CJSJ-200 gear compound machine tool electrical control design AbstractThe article mainly has carried on the CJSJ-200 gear compound machine tool electrical control design. Mainly used for SIEMENS 828D of NC system,using the numerical control system of the compact, simple to use, realize the harmony of the best surface quality and high speed and high precision for the design of electrical control. For gear composite processing and electric control design is mainly through PLC program design system to control the drive of the whole system,to directly control the machine tool parts, various and precise action and movement precision is very high. In addition to the research on composite processing gear is also of great practical use, both reduces the working procedure,and improves the efficiency and accuracy, further promotion and application of composite machine tools will be more and more. The trapezoidal diagram of PLC control program and install the drive system, analysis of the program in the process of system debugging, ...
