球罐组装几何尺寸报告 № 1/1 JSH01-26工程名称Project Name巴尼亚斯 LPG 罐区扩建工程Banias LPG tank expansion project球罐名称Tank Name3000m3混合液化石油气球罐3000m3LPG Shperical Tank球罐编号Tank NO.V0101F设计尺寸Design sizeSφ17900X38材料牌号MaterialSA516 Gr.70N设计内径Design inside diameterφ17900mmδΔD 直径允差Diameter allowable deviation50mmDmax—Dmin14mm测点Measurement项目itemd1d2d3d4d5d6d7d8d9d10DmaxDmin179011790317902179031790117899179041790417905179021790217899S117903S217904S317904管口号 nozzles项目 itemabcdefghK1K2LM1M2p1p2p3st1t2xΔH管口水平偏差nozzles level deviation12322123112123322231检验责任工程师： 检验员：Examiner engineer Inspector
