监控中心系统建设设计方案陕西导航科技有限公司技术部：周亚杰2013年11月目录1、概述·················································31.1、项目概况········································31.2、设计原则········································31.3、总体目标········································41.4、设计依据········································42、系统总体设计·········································52.1、网络拓扑图······································52.2、集中管理设计····································52.2.1、数据库管理··································52.2.2、服务器管理··································62.2.3、软件客户端功能······························62.3、中心机房设计····································72.3.1、机房效果图································102.4、显示管理设计····································122.4.1、系统特点····································122.4.2、系统结构····································132.4.3、嵌入式系统··································132.4.4、拼接显示组合································142.4.5、系统显示预案································142.4.6、技术指标····································153、设备清单与报价·······································161、概述1.1、项目概况监控中心所选用的硬盘录像服务器和显示器，将会对所有摄像机进行24小时录像。本系统可在局域网内任意电脑实现分控，并按实际情况分配权限，所有摄像机的监视图像均可在监控室内显示，并能实时录像。硬盘录像服务器内置高速硬盘，并配置TB级存储器，容量不低于动态录像储存1个月的空间，并可随时调阅及快速检索。1.2、设计原则（1）.实用性本系统将完全满足监控各项安防需求，考虑未来发展需求，基于成熟的IP网络来传输。追求系统的适当超前性，以减少不必要的投资。（2）.可靠性、安全性参照大量已建成的项目相关安防监控系统，借鉴其中的精华部分，为系统高可靠性的总体设计提供现实依据，选用的设备自身将具备高可靠性、高安全性，高达数万小时的平均无故障时间，并为关键设备、关键部件设计冗余备份。（3）.先进性本系统设计遵循系统工程的设计准则，通过科学合理地设计，最大程度地采用成熟、可继承、具备广阔发展前景的先进技术，使系统能在未来数年内不落后，并通过软件升级即可实现更多新功能，充分保护用户的投资。（4）.开放性本系统设计将采用标准化设计，严格遵循相关技术的国际、国内和行业标准，确保系统之间的透明性和互通互联，并充分考虑与其它监控系统的连接。在设计和设备选型时，将科学预测未来扩容需求，进行余量设计。（5）.易管理性、易维护性本系统将采用全中文、图形化软件平台实现整个监控系统管理与维护。可自动检测系统中任何一台设备的运行状态，并示出详细参数，以辅佐管理人员及时准确地判断和解决问题。采用稳定易用的硬件和软件，完全不需借助任何专用维护工具。（6）.灵活的部署方式根据实际业务需求，...
