SEMICO 双极集成电路产品目录 型号 名称及主要特点 工作电压 封装 单页资料 2.1 单片彩色电视机电路 CD8690CP NTSC/PAL制单片彩色电视机电路 1-Chip PAL/NTSC CTV Circuit with OSD 9V (typ.) SDIP54 2.2 图像伴音中放电路 CD7176CP 伴音中频放大电路 TV Sound IF Amp. 12V (typ.) DIP14 CD7243CP 带功放的伴音中频放大电路 TV Sound System with Power Amp. 15 ~ 30V FDIP14 CD7510CS 准分离伴音中频放大电路 Quasi-parallel Intercarrier Detector 12V (typ.) SIP9 CD7607CP 图像中频放大电路（反向 RF AGC） PIF System with Reverse RF AGC 12V (typ.) DIP16 CD7680CP 图像伴音中频放大电路（反向 RF AGC） CTV PIF & SIF System with Reverse RFAGC 12V (typ.) DIP24 CD7681CP 图像伴音中频放大电路（正向 RF AGC） CTV PIF & SIF System with Forward RF AGC 12V (typ.) DIP24 2.3 色处理及行场扫描电路 CD7193CP PAL制色信号处理电路 PAL Chroma System 12V (typ.) DIP24 CD7193PCP PAL制色信号处理电路 PAL Chroma System 12V (typ.) DIP24 CD7609CP 行场扫描电路 TV Deflection System 12V (typ.) DIP16 CD7698CP PAL/NTSC制色信号处理及行场扫描电路 PAL/NTSC Video、Chroma and Deflection System 12V (typ.) DIP42 CD8759CP 全制式彩电色处理及行场扫描电路 Video、Chroma and Deflection for PAL/SECAM/NTSC Multi-Color System 12V (typ.) SDIP64 CD78040CZ 总线控制的场功放电路 TV Vertical Deflection Output Circuit with Bus Control 24V (typ.) TO-220 (FZIP7) CD78040NCZ 总线控制的场功放电路 TV Vertical Deflection Output Circuit with Bus Control 24V (typ.) TO-220 (FZIP7) CD78041CZ 总线控制的场功放电路 TV Vertical Deflection Output Circuit with Bus Control 24V (typ.) TO-220 (FZIP7) CD7830CS 场功放电路 TV Vertical Deflection Output Circuit 24V (typ.) FSIP7 CD7832CS 场功放电路 TV Vertical Deflection Output Circuit 24V (typ.) FSIP7 CD7840GS 总线控制的场功放电路 TV Vertical Deflection Output Circuit with Bus Control 24V (typ.) FSIP7 下载 CD7841GS ...
