ABBm马达起动器MS132

Description –Overload protection – trip class 10 –Phase loss sensitivity –Disconnect function –Temperature compensation from -25 … +60 °C –Adjustable current setting for overload protection –Suitable for three- and single-phase application –Trip-free mechanism –Status indication –Clear switch position indication ON/OFF/TRIP –Lockable handle Order dataMS132 screw terminalSetting range ATypeTrip classOrder codePacking unitPCEWeight per PCEkg0.10...0.16MS132-0.1610A1SAM350000R100110.2150.16...0.25 MS132-0.25101SAM350000R100210.2150.25...0.40MS132-0.4101SAM350000R100310.2150.40...0.63 MS132-0.63101SAM350000R100410.2150.63...1.00 MS132-1.0101SAM350000R100510.2151.00...1.60 MS132-1.6101SAM350000R100610.2651.60...2.50 MS132-2.5101SAM350000R100710.2652.50...4.00 MS132-4.0101SAM350000R100810.2654.00...6.30 MS132-6.3101SAM350000R100910.2656.30...10.00 MS132-10101SAM350000R101010.2658.00...12.00 MS132-12 101SAM350000R1012 10.31010.00...16.00 MS132-16101SAM350000R101110.31016.00...20.00 MS132-20101SAM350000R101310.31020.00...25.00 MS132-25101SAM350000R101410.31025.00...32.00 MS132-32101SAM350000R101510.310Note: MS132 with pre-assembled auxiliary contact HKF1-11, please order as follow 1SAM350005RxxxxManual motor starters are electro-mechanical protection devices for the main circuit. They are used mainly to switch motors manually ON/OFF and protect them fuse less against short-circuit, overload and phase failures. Fuse less protection with a manual motor starter saves costs, space and ensures a quick reaction under short-circuit condition, by switching off the motor within milliseconds. Fuse less starter combinations are setup together with contactors.Manu al motor starter MS132Data sheet2CDC241020F0009ApprovalsAcULus UL 508KCB schemeABSECCCDGOST-RGOST-FPLloyd’s RegisterGLDNVRINAMarksaCE2 - 2CDC131021D0201Func...
