本表内尺寸这参考值，可根据用户要求进行设计。 型号 额定电压 额定频率 额定容量（Kvar） 额定电容（μ F） 额定电流（A） 尺寸（L×D×H） BSMJ0.4-1-3 0.4 （KV） 50 （Hz） 1 19.9 1.4 165×56×130 BSMJ0.4-2-3 2 39.8 2.9 165×56×130 BSMJ0.4-3-3 3 59.7 4.3 165×56×130 BSMJ0.4-4-3 4 79.6 5.8 165×56×130 BSMJ0.4-5-3 5 99.5 7.2 165×56×130 BSMJ0.4-6-3 6 119.4 8.7 165×56×130 BSMJ0.4-7.5-3 7.5 149.3 10.1 165×56×130 BSMJ0.4-8-3 8 159.2 11.5 165×56×130 BSMJ0.4-10-3 10 199 14.4 165×56×180 BSMJ0.4-12-3 12 238.9 17.3 165×56×180 BSMJ0.4-14-3 14 278.7 20.2 165×56×195 BSMJ0.4-15-3 15 298.6 21.7 165×56×195 BSMJ0.4-16-3 16 318.5 23.1 165×56×195 BSMJ0.4-18-3 18 358.3 26.0 165×56×250 BSMJ0.4-20-3 20 398.1 28.9 165×56×250 BSMJ0.4-25-3 25 497.6 36.1 170×87×230 BSMJ0.4-30-3 30 597.1 43.3 180×95×320 BSMJ0.4-40-3 40 796.2 57.7 180×95×320 BSMJ0.4-50-3 50 995.2 72.2 270×120×270 BSMJ0.4-60-3 60 1194.3 86.6 270×120×320 0.45KV系列（0.45KVSERICE） 型号 额定电压（KV） 额定频率（Hz） 额定容量（Kvar） 额定电容（μ F） 额定电流（A） 尺寸（L×D×H） BSMJ0.45-1-3 0.45 50 1 15.7 1.3 165×56×130 BSMJ0.45-2-3 2 31.4 2.6 165×56×130 BSMJ0.45-3-3 3 47.1 3.8 165×56×130 BSMJ0.45-4-3 4 62.9 5.1 165×56×130 BSMJ0.45-5-3 5 78.6 6.4 165×56×130 BSMJ0.45-6-3 6 94.3 7.7 165× 56× 130 BSMJ0.45-7.5-3 7.5 117.9 9.6 165× 56× 130 BSMJ0.45-8-3 8 125.8 10.3 165× 56× 130 BSMJ0.45-10-3 10 157.2 12.8 165× 56× 180 BSMJ0.45-12-3 12 188.7 15.4 165× 56× 180 BSMJ0.45-14-3 14 219.8 17.9 165× 56× 195 BSMJ0.45-15-3 15 235.9 19.2 165× 56× 195 BSMJ0.45-16-3 16 251.6 20.5 165× 56× 195 BSMJ0.45-18-3 18 283 23 165× 56× 250 BSMJ0.45-20-3 20 314.5 25.6 165× 56× 250 BSMJ0.45-25-3 25 393 32 170× 87× 230 BSMJ0.45-30-3 30 471.8 38.4 180× 95× 320 BSMJ0.45-40...
