JC长轴深井泵使用方法

苏华泵业中国优质产品ISO9000认证JC 型长轴深井泵JCTYPELINE-SHAFTDEEPWELLPUMP产品简介 PRODUCTION INTRODUCTIONJC 型系列深井泵结构先进，采用亚什兰树脂工艺制芯，叶轮、导流壳流道部位使用环氧涂复新工艺、水力模型先进、性能曲线无驼峰、高效区域宽广，采用甩沙式防沙环，迷宫结构，使沙子无法进入轴承，传动轴采用先进的热校直工艺，是新一代节能型提水机具。流量：≤2500m³/h扬程：≤350m电机功率：5.5-710KW额定电压：380V,6KV,10KV井径：100-750mm最大排出口径：450mmJC series deep well pumps are new generation and energy-saving equipment for lifting water.They are with advanced structure, for they adopting the core produced with the resin sand and theimpeller&diffuser adopting the new technique that top coated with epoxy, advanced hydraulicmodel, excellent performance curve without hump and wide high efficiency range. They use whirlsand device and the maze-like structure which makes sand not able to enter the bearings. Shaft ischecked by flame method to ensure it is in line.Capacity: ≤2500m³/hHead: ≤350mMotor Power: 5.5-710KWRated Voltage: 380V,6KV,10KVWell Diameter: 100-750mmMax Discharge Diameter: 450mm应用范围 USEAGE RANGEJC 型长轴深井泵适用于从水井中提取常温无腐蚀性的清水，广泛应用于水电站（检修、渗漏排水用泵），火电厂（循环降温，生活用泵），钢厂（铁皮坑用泵），消防，城镇水厂供水及农田灌溉。JC series deep well pumps are applied to lift normal temperature clean water without erosive forwater power plant(in an overhaul and leakage), power plant(when reduce the temperature in therecycle, and for domestic service), steel works(for scale pit), fire-fighting, urban water supply bywater plant and agriculture irrigation.安装使用方式 INSTALLATION METHOD深井提水水池江河排水筒式安装抽水凝水管道增压Lift water fromDrain water from cisternBarrel mode installationIncrease water pressuredeep wellfor water drainagein conduit内燃机驱动直角齿轮箱传...
