理工学院本科生毕业设计(论文)学院(系):专 业:学 生:指导老师: 完成日期 2024 年 5 月理工学院毕业设计(论文)超声波测距系统的硬件设计TheHardware Design Of Ultrasonic Ranging Systerm 总 计: 32 页 表 格: 4 个插 图 : 17 幅南 阳 理 工 学 院 本 科 毕 业 设 计(论文)超声波测距系统的硬件设计TheHardware Design of Ultrasonic Ranging Systerm学 院(系):专 业:学 生 姓 名:学 号:指 导 教 师(职称):评 阅 教 师:完 成 日 期:2024.05.10 Nanyang Institute of Technology超声波测距系统的硬件设计测控技术与仪器 [摘 要]超声波测距器,可以应用于汽车倒车、建筑施工施工场地以与一些工业现场的位置监控,也可用于如液位、井深、管道长度的测量等场合。在本次设计中,设计的超声波测距系统的测量精度为 1cm,能够清楚稳定地显示测量结果。在整个超声波测距硬件电路模块中主要的电路设计有超声波发射电路、超声波接收电路、显示电路、温度补偿电路以与声光报警电路构成。其中接收电路主要采纳的是 CX20106A;发射电路采纳的是反相器 74HC04 与超声波发射换能器组成;另外,为了提高测量的精度在电路中又加入了温度补偿装置,DS18B20 就是用来测量当前温度从而来实现这一功能。通过实物验证这一设计方案是可行的。[关键词]STC89C52;超声波测距;74HC04;CX20106A;温度补偿TheHardware Design of Ultrasonic RangingSystermTracking Control Technology and EquipmentAbstract:Ultrasonic range finder, can be applied to the car into reverse, the construction sites and industrial the position to monitor and may be used as the old, dark, the length of such occasions. In the design of system design, precision measurement range of ultrasonic, the stability of 1cm clear that measurement.In the whole range of ultrasonic hardware circuit that the main circuit design has an ultrasonic the circuit, an ultrasound the circuit, show circuit, temperature compensate circuit and theaudible and visible police made a circuit.One of the main circuits are CX20246A ;The circuit is the use of ...
