段名辉基于 PLC 的沼气池自动控制系统设计2025 届本科生毕业设计 分类号:TP911 题目: 基于 PLC 的沼气池自动控制系统设计 作 者 姓 名: 段 名 辉 学 号: 学 院: 机械与电子工程学院 专 业: 电气工程及其 自动化 指导老师姓名: 邵毅 彭二飞 指导老师职称: 讲师 工程师 2025 年 5 月 10 日摘 要本设计是基于PLC的沼气自动控制系统。系统的控制核心采纳西门子S7300 PLC控制器。控制程序采纳STEP 7软件编写。利用WinCC flexible软件设计人机界面实现系统的实时监控。通过人机界面输入相应的控制信号对沼气池的各个执行机构进行控制。该系统可以对采集到的数据进行转换。实际值与设定值进行比较实现对沼气的智能控制。在实验室调试过程中,控制器运行良好。触摸屏操作简便,具有较强的可靠性和有用性,满足现场控制的要求,达到了设计目标。关键词:沼气控制;可编程控制器;人机界面 ABSTRACTThis design is a PLC-based automatic methane control system. The Siemens S7-300 PLC controller is the core of the system. The control program is compiled by using the STEP 7 software. The human-machine interface is designed with the WinCC flexible software to realize the real-time monitoring of the system. By inputting the corresponding control signal through the human-machine interface, each actuating mechanism of the methane tank can be controlled. The system is able to convert the data it collected. Comparison between the actual value and set value can be performed, to realize the intelligent control of the methane tank. The controller runs well during debugging in the laboratory. The touch screen is easy to operate and highly reliable and practical, meeting the requirement of on-site control and realizing the design target.Keywords: Methane control; Programmable controller; Human-machine interface 目 录绪论....................................................................................................................................11 系统总体设计.........
