1© 2007. HiRain Technologies. All rights reserved.Slide: CANoe 概述CAN 总线开发工具测试分析仿真记录2© 2007. HiRain Technologies. All rights reserved.Slide: CANoe 在总线开发中的作用（ 1 ）Phase 1simul.nodensimul.node2Simulated bus…simul.node1ωKl 15Virtual total system…3© 2007. HiRain Technologies. All rights reserved.Slide: CANoe 在总线开发中的作用（ 2 ）Phase 2simul.node2simulated rest-of-bus…realnode1ωKl 15simul.nodenVirtual subystemReal subsystem…phys. bus4© 2007. HiRain Technologies. All rights reserved.Slide: CANoe 在总线开发中的作用（ 3 ）Phase 3realnode2…realnode1ωKl 15Real total systemrealnoden…Physical busAnalysis(in real-time)5© 2007. HiRain Technologies. All rights reserved.Slide: 硬件接口卡 &“ 狗”CANcardXLCANcaseXL收发器CANcab (CANpiggy)251, 1041, 1054…LINcab (LINpiggy)7259CAN 卡6© 2007. HiRain Technologies. All rights reserved.Slide: CANoe 组成功能强大、操作简单CANoe数据库支持CANdb++ Editor可编程CAPL虚拟仪表Panel Editor & Panel Designer7© 2007. HiRain Technologies. All rights reserved.Slide: CANoe 工程环境8© 2007. HiRain Technologies. All rights reserved.Slide: 多总线软件硬件控制面板Vector Hardware•License->Overview9© 2007. HiRain Technologies. All rights reserved.Slide: 设置（ 1 ）硬件CAN 卡类型（编号）收发器类型应用程序通道应用程序License 信息10© 2007. HiRain Technologies. All rights reserved.Slide: 设置（ 2 ）CANoe通道设置Configuration->OptionsConfiguration Settings->Channel Usage11© 2007. HiRain Technologies. All rights reserved.Slide: 灵活＝复杂HW channelsChannel1 Channel2 Channel1 Channel2 PiggyBack1 PiggyBack2CANcardXL #1CANcaseXLCANcardXL #2HardwareCANalyzer1 CANalyzer2... CANoe1 CANoe2 CANoe1 for LIN...App channelsApplication12© 2007. HiRain Technologies. All rights reserved.Slide: 从复杂到简单CANoe...
