1LT1013/LT101410134fbQu ad Precision Op Amp (LT1014)Du al Precision Op Amp (LT1013)The LT®1014 is the first precision quad operational amplifierwhich directly upgrades designs in the industry standard14-pin DIP LM324/LM348/OP-11/4156 pin configuration.It is no longer necessary to compromise specifications,while saving board space and cost, as compared to singleoperational amplifiers.The LT1014’s low offset voltage of 50µV, drift of 0.3µV/°C,offset current of 0.15nA, gain of 8 million, common moderejection of 117dB and power supply rejection of 120dBqualify it as four truly precision operational amplifiers.Particularly important is the low offset voltage, since nooffset null terminals are provided in the quad configura-tion. Although supply current is only 350µA per amplifier,a new output stage design sources and sinks in excess of20mA of load current, while retaining high voltage gain.Similarly, the LT1013 is the first precision dual op amp inthe 8-pin industry standard configuration, upgrading theperformance of such popular devices as the MC1458/1558, LM158 and OP-221. The LT1013’s specificationsare similar to (even somewhat better than) the LT1014’s.Both the LT1013 and LT1014 can be operated off a single5V power supply: input common mode range includesground; the output can also swing to within a few millivoltsof ground. Crossover distortion, so apparent on previoussingle-supply designs, is eliminated. A full set of specifi-cations is provided with ±15V and single 5V supplies.s Single Supply OperationInput Voltage Range Extends to GroundOutput Swings to Ground while Sinking Currents Pin Compatible to 1458 and 324 with Precision Specss Guaranteed Offset Voltage: 150µV Maxs Guaranteed Low Drift: 2µV/°C Maxs Guaran...
