第130页 集成交互式道路路线设计系统——EICAD 用户手册 平交口设计部分 南京狄诺尼科技有限责任公司 CAD 事业部 第六篇 EICAD 平交口设计部分使用说明 目录 平交口设计程序概述 ..................................................... 131 1、Ei_PJSetting 平交口设置命令 ··················································································· 132 2、Ei_AddZHCtrl 添加路脊线控制高程命令 ···································································· 133 3、Ei_PJEleSetting 平交口高程设置命令 ········································································ 133 4、Ei_PJList 平交口路面查询与标注命令 ······································································· 135 5、Ei_PJDrawDGX 绘制等高线命令 ·············································································· 136 6、Ei_PJSetPDColor 坡度色彩对照表命令 ······································································ 136 7、Ei_PJDimR 标注转角半径命令 ················································································· 136 8、Ei_PJDimB 标注宽度命令 ······················································································· 137 9、Ei_PJDimC 标注交叉点命令 ···················································································...
