编号 图形符号 名 称 英 文 说 明 3.1 周界防护装置及防区等级符号 3.1.1 栅栏 fence 单位地域界标 3.1.2 监视区边界 monitored zone 区内有监控,人员出入受控制 3.1.3 保护区边界(防护区) protective zone 全部在严密监控防护之下,人员出入受限制 3.1.4 加强保护区边界(禁区) forbidden zone 位于保护区内,人员出入禁区受严格限制 3.1.5 保安巡逻打卡器 security cruise station 3.1.6 警戒电缆传感器 guardwire cablesensor 3.1.7 警戒感应处理器 guardwire sensor processor 长方形: 长∶宽=1∶0.6 3.1.8 周界报警控制器 console 3.1.9 接口盒 interface box 编号 图形符号 名 称 英 文 说 明 3.1.10 主动红外探测器 active infrared intrusion detector 发射、接收分别为 Tx、Rx 引用 BS 4737-5.2:1998 3.1.11 引力导线探测器 tensioned wire detector 引用 BS 4737-5.2:1998 3.1.12 静电场或电磁场探测器 electrostatic or electromagnetic fence detector 引用 BS 4737-5.2:1998 3.1.13 遮挡式微波探测器 microwave fence detector 引用 BS 4737-5.2:1998 3.1.14 埋入线电场扰动探测器 buried line field disturbance detector 引用 BS 4737-5.2:1998 3.1.15 弯曲或震动电缆探测器 flex or shock sensitive cable detector 引用 BS 4737-5.2:1998 3.1.16 拾音器电缆探测器 microphone cable detector 引用 BS 4737-5.2:1998 3.1.17 光缆探测器 fibre optic cable detector 引用BS 4737-5.2:1998 3.1.18 压力差探测器 pressu re differential detector 引用BS 4737-5.2:1998 3.1.19 高压脉冲探测器 high-v oltage pu lse detector 3.1.20 激光探测器 laser detector 3.2 出入口控制设备 access control equ ipment 3.2.1 楼宇对讲系统主机 main control modu le for flat intercom electrical control sy stem 3.2.2 对讲电话分机 interphone handset 3.2.3 可视对讲摄像机 v ideo entry secu rity intercom camera 3.2.4 可视对讲机 v ideo entry secu rity intercom 3.2.5 电控锁 electro-mechanical lock 编号 图形符号 名 称 英 文 说 明 3.2.6 卡控旋转栅门 3.2.7 卡控旋转门 3.2.8 卡控叉形转栏 ...
