循环球式转向器的设计目 录摘要........................................................Ⅰ1 绪论 11.1 课题背景 11.2 国外讨论现状 21.3 讨论目的与意义 31.4 讨论容和设计方法 32 转向器的设计 42.1 转向系统简介 42.2 机械转向系 52.2.1 转向操纵机构 52.2.2 转向器 62.2.3 转向传动机构 92.3 转向系主要性能参数 92.3.1 转向器的效率 92.3.2 传动比的变化特性 102.4 主要尺寸参数的选择 122.4.1 螺杆、钢球、螺母传动副设计 152.4.2 齿条、齿扇传动副设计 172.5 转向器的计算和校核 182.5.1 循环球式转向器零件的强度计算 182.5.2 转向摇臂轴直径的确定 203 三维模型与二维工程图 213.1 三维模型零件图 213.2 二维工程图 243.2.1 零件图的绘制 243.2.2 总装图的绘制 264 结论 27致 28参考文献 29轻型越野车循环球式转向器的设计[摘要]汽车是一种性能要求高,负荷变化大的运输工具。转向系统作为汽车的关键部件之一,更需要了解和掌握。转向器作为转向系统中最重要的组成部件,对它进行深化的讨论便显得意义重大。循环球式转向器主要由螺杆、螺母、钢球、转向器壳体等组成,具有较高的传动效率,操纵轻便,磨损较小,使用寿命长,近年来得到广泛使用。根据现用的国家标准并依据 BJ2024 汽车的循环球转向器数据,根据汽车设计的原则设计一款循环球转向器,完成三维图形和零件平面图的绘制,使其能够满足现代越野车的国家标准要求。[关键词]循环球转向器设计 分析 越野车The design on circulating ball type steering gear for a light off-road vehicle[Abstract]Automobile is a transport machine with high-performance and variable loads. Steering system is one of the key components for vehicles and need to be understood and grasped. As the most important part of steering system, steering gear need to be studied importantly. Circulating ball-type steering gear containsscrew, nut, ball, steering gear housing, etc.It has many Advantages, such as high transmission efficiency, light manipulation, less wear and long service life, so as tobe widely used in recent years. According to current national standards and the ball steeri...
