半桥式开关电源设计(52 页)Good is good, but better carries it.精益求精，善益求善。半桥式开关电源设计摘 要随着电子技术的高速进展,电子系统的应用领域越来越广,电子设备的种类也越来越多,电子设备与我们的工作、生活的关系日益密切。近年来 ,随着功率电子器件(如 IGBT、MOSFET)、PWM 技术以及电源理论的快速进展 ,新一代的电源电路开始逐步取代传统的电源电路。该电源电路具有体积小，控制灵活方便，输出特性好、纹波小、负载调整率高等显著优点。由于开关电源中的功率调整管工作在开关状态，具有功耗小、效率高、稳压范围宽、温升低、体积小等突出优点，因此在通信设备、数控装置、仪器仪表、视频音响、家用电器等电子电路中得到广泛应用。开关电源的高频变换电路形式很多, 常用的变换电路有推挽、全桥、半桥、单端正激式和单端反激式等形式。本论文采纳双端驱动集成电路——TL494 输的 PWM 脉冲控制器设计音响设备供电电源，利用 BJT 管作为开关管，可以提高电源变压器的工作效率，有利于抑制脉冲干扰，同时还可以减小电源变压器的体积。关键词：TL494，PWM，半桥式电路，开关电源Design of Half Bridge Switching Power Supply ABSTRACTWith the rapid development of electronic technology, electronic systems, more and more extensive applications, the types of electronic equipment, more and more electronic equipment and people work and live closer and closer. In recent years, with the power electronic devices (such as IGBT, MOSFET), PWM switching power supply technology and development of the theory, a new generation of power began to gradually replace the traditional power supply circuits. The circuit is small, flexible to control the output characteristics of a good, ripple, load adjustment rate and so on.Switching power supply in the power adjustment control work in the off state, with low power consumption, high efficiency, wide voltage range, low temperature rise, and other outstanding advantages of small size, the communication equipment, CNC equipment, Instrumentation, video audio, home a...
