Microchip-PIC32MZ-32位MCU嵌入连接解决方案

Microchip PIC32MZ 32 位 MCU 嵌入连接解决方案Microchip 公司的 PIC32MZ 是 200MHz 32 位嵌入联 MCU，具有高达 2MB 闪存,512KB RAM, 10/100 以太网 MAC，高速 USB MAC/PHY 和两个 CAN 端口，处理器性能高达 330 DMIPS 和 3。28 CoreMark/MHz，支持 WQVGA 图像，可用新一代嵌入设备.本文介绍了 PIC32MZ 主要特性和框图, MIPS32＆reg ； microAptiv 微处理器核主要特性和框图,以及 PIC32MZ 嵌入式连接（CE）入门板主要特性，电路图,材料清单和 PCB 元件布局图。The PIC32MZ Embedded Connectivity family of 200 MHz 32-bit microcontrollers feature up to 2 Mbytes of flash, 512 Kbytes of RAM, a 10/100 Ethernet MAC ， Hi—Speed USB MAC/PHY, and dual CAN ports. The processors yield 330 DMIPS and 3.28 CoreMark/MHz performance, with an interrupt latency of only 10 clock cycles, and have direct support for a WQVGA graphics。The chips are said to have class-leading code density and have a 28 Ms/s 12—bit A/D converter and a crypto engine with a random number generator. They use Imagination’s MIPS microAptiv core ， which includes 159 DSP instructions that enable algorithms with up to 75 ％ fewer cycles than previous MCU versions 。 QFN ， TQFP ， VTLA ， and LQFP packages with 64 to 144 pins are available starting in December and priced from 6。68 ea/10，000. A starter kit is available。PIC32MZ 主要特性:Operating Conditions&bull；2。2V to 3。6V, —40＆ordm;C to +85＆ordm；C, DC to 200 MHz&bull；2。2V to 3。6V, -40＆ordm；C to +125º；C （Planned）Core: 200 MHz (up to 330 DMIPS) microAptiv&trade；＆bull；16 KB I-Cache, 4 KB D—Cache&bull；MMU for optimum embedded OS execution•microMIPS＆trade; mode for up to 35 ％ smaller code size＆bull；DSP-enhanced core—： Four 64-bit accumulators—Single-cycle MAC, saturating and fractional math&bull；Code—efficient （C and Assembl...
