ERA2000成像测井地面仪器硬件的设计与实现VIP免费

ERA2000 成像测井地面仪器硬件的设计与实现3艾时钟 李安宗 武向萍 陈文辉 王怡红(西安石油勘探仪器总厂)摘要艾时钟 ,李安宗 ,武向萍等. ERA2000 成像测井地面仪器硬件的设计与实现. 测井技术 ,2002 ,26( 6) :523～526ERA2000 成像测井地面仪的设计采用了先进的计算机技术和网络技术 ,成功地解决了成像测井数据量大、外部响应多等问题 ,解决了采集数据要求的可靠性高、实时性强以及数据的成像处理、解释绘图输出等几个方面的技术难题。分别介绍了设计思想、功能、特点和系统的实现方式。地面数据采集使用具有国际标准的工业总线 VME 总线 ,提高了系统的稳定性和可靠性。操作系统使用对用户友好的窗口界面 ,具有配套齐全、组合测井能力强、工作稳定可靠、操作使用方便等特点。能够完成成像测井、常规裸眼井测井、生产测井、射孔作业以及特殊的中子寿命测井和地层测试等功能。关键词 : 成像测井 地面系统 数据采集 硬件 设计ABSTRACTAi Shizhong , Li Anzong , Wu Xiangping ,et al. .The Design and Realization of Hardware inERA2000 Imaging Logging Surface System. WLT, 2002 , 26( 6) :523 - 526According to the need of complicated exploration & development in oil fields , ERA2000 ( Earth Re2sources Acquisition 2000) imaging logging surface system has been developed by XPEIC. It has solvedmany technical probelms , such as tremendous image data processing , handling of numerous external re2spones and output of the interpretation curves. The ERA 2000 imaging logging system design is based onoperating system of Windows N T and VxWorks and avoids the infection of virus , therefore , it allows torun stably and normally. Advanced computer and network technology are used , and international standard2ized VME bus has been used in data acquisition to enhance system′ s stability and reliability. The systemkeeps ahead in real ν time logging images processing. The operating system has user ν friendly windowinterfaces. It can be connected with neutron lifetime loggin...
