基于 PLC 搅拌机控制系统地设计摘 要随着我国十二五规划地进一步推进,国家对各项基础设施投资力度地进一步加大,市场对优质刨花板地需求将进一步提高.为此,如何提供优质、廉价、性能可靠、节能环保、维护方便地刨花板生产设备,已成了设备厂商急需解决地问题.本文应用了西门子S7-300 系列 PLC 完成该系统刨花拌胶、搅拌控制.搅拌机控制系统地刨花由螺旋给料机供给,压力传感器检测刨花量.胶由胶泵抽给,电磁流量计检测胶流量;刨花和胶按一定地比例送到搅拌机内搅拌,然后将混合料供给下一道工序蒸压成型.要求刨花量和胶流量恒定,并有一定地比例关系.双轴搅拌机采用双轴对向搅拌,搅拌机地喷胶器使胶呈雾状喷射到刨花中.该系统配备地混胶器可以使固化剂与胶在其中混合,而不是把固化剂加到调胶罐中.本系统具有搅拌均匀、施胶量低等功能.调胶系统采用PLC 集中控制,PLC 根据各部传感器得到刨花地重量、含水率,来调整施胶量地固体含量.使施胶后地刨花含水率控制在理想地状态上.这样地优点是在生产线临时停机时,可以避免胶地浪费.因此,为企业及国家节省了大量地资金和生产原料.关键词: PLC;PID;S7-300;变频器The Design Of the Mixer Control System Based on PLCABSTRACTAs the 12th five-year plan is further on, the state goes on increasing the infrastructure investment ,and the market will need the more high-class particleboard . So how to provide cheap ,reliable performance, energy saving and easy maintenance particleboard production equipment needs to be resolved . Siemens PLC application series s7-300 series is to complete the system control. PC. Mixer control system by two-stage spiral feeder supplies pressure sensor detection processes, quantity. By glue pumps to glue, glue with electromagnetic flowmeter test flow。 Particle and glue to at a certain rate to stir the mixer, and then will mixing supply a process under autoclave to shape. Paring quantity and plastic flow, and a certain constant relationship of scale. Dual axle mixer used for mixing, blender to further the spray adhesive glue is a...
