c_ms_chart_控件使用方法汇总(附统计图)

c# ms chart 控件使用方法 第一个简单的chart：创建曲线图 chart1.Series.Clear(); Series series = new Series("Spline"); series.ChartType = SeriesChartType.Spline; series.BorderWidth = 3; series.ShadowOffset = 2; // Populate new series with data series.Points.AddY(67); series.Points.AddY(57); series.Points.AddY(83); series.Points.AddY(23); series.Points.AddY(70); series.Points.AddY(60); series.Points.AddY(90); series.Points.AddY(20); // Add series into the chart's series collection chart1.Series.Add(series); 同时显示 2 条曲线 // Populate series with random data Random random = new Random(); for (int pointIndex = 0; pointIndex < 10;pointIndex++) { Chart1.Series["Series1"].Points.AddY(random.Next(45, 95)); Chart1.Series["Series2"].Points.AddY(random.Next(5, 75)); } // Set series chart type Chart1.Series["Series1"].ChartType = SeriesChartType.Line; Chart1.Series["Series2"].ChartType = SeriesChartType.Spline; // Set point labels Chart1.Series["Series1"].IsValueShownAsLabel = true; Chart1.Series["Series2"].IsValueShownAsLabel = true; // Enable X axis margin Chart1.ChartAreas["ChartArea1"].AxisX.IsMarginVisible = true; // Enable 3D, and show data point marker lines Chart1.ChartAreas["ChartArea1"].Area3DStyle.Enable3D = true; Chart1.Series["Series1"]["ShowMarkerLines"] = "True"; Chart1.Series["Series2"]["ShowMarkerLines"] = "True"; 显示column 类型图,柱状图 // Create new data series and set it's visual attributes Chart1.Series.Clear(); Series series = new Series("FlowRead"); series.ChartType = SeriesChartType.Column; series.BorderWidth = 3; series.ShadowOffset = 2; // Populate new series with data series.Points.AddY(67); series.Points.AddY(57); series.Points.AddY(83); series.Points.AddY(23); series.Points.AddY(70); series.Points.AddY(60); series.Points.AddY(90); series.Points.AddY(20); // Add series into the chart'...
