1 华为三康(H3C)三层交换机 VLAN配置实例 dis cu # sysname H3C # radius scheme system # domain system # acl number 2011 rule 0 deny rule 1 permit source 172.16.11.0 0.0.0.255 acl number 2012 rule 0 deny rule 1 permit source 172.16.12.0 0.0.0.255 acl number 2013 rule 0 deny rule 1 permit source 172.16.13.0 0.0.0.255 acl number 2021 rule 0 deny rule 1 permit source 172.16.21.0 0.0.0.255 acl number 2022 rule 0 deny rule 1 permit source 172.16.22.0 0.0.0.255 acl number 2023 rule 0 deny rule 1 permit source 172.16.23.0 0.0.0.255 acl number 2031 rule 0 deny rule 1 permit source 172.16.31.0 0.0.0.255 acl number 2032 rule 0 deny rule 1 permit source 172.16.32.0 0.0.0.255 acl number 2033 rule 0 deny rule 1 permit source 172.16.33.0 0.0.0.255 acl number 2041 rule 0 deny rule 1 permit source 172.16.41.0 0.0.0.255 acl number 2042 rule 0 deny 2 rule 1 permit source 172.16.42.0 0.0.0.255 acl number 2043 rule 0 deny rule 1 permit source 172.16.43.0 0.0.0.255 acl number 2080 rule 0 deny rule 1 permit source 172.16.80.0 0.0.0.255 # vlan 1 # vlan 11 # vlan 12 # vlan 13 # vlan 21 # vlan 22 # vlan 23 # vlan 31 # vlan 32 # vlan 33 # vlan 41 # vlan 42 # vlan 43 # vlan 80 # interface Aux1/0/0 # interface Ethernet1/0/1 port link-type hybrid port hybrid vlan 1 11 untagged port hybrid pvid vlan 11 packet-filter inbound ip-group 2011 rule 0 packet-filter inbound ip-group 2011 rule 1 3 # interface Ethernet1/0/2 port link-type hybrid port hybrid vlan 1 12 untagged port hybrid pvid vlan 12 packet-filter inbound ip-group 2012 rule 0 packet-filter inbound ip-group 2012 rule 1 # interface Ethernet1/0/3 port link-type hybrid port hybrid vlan 1 13 untagged port hybrid pvid vlan 13 packet-filter inbo...

1、当您付费下载文档后，您只拥有了使用权限，并不意味着购买了版权，文档只能用于自身使用，不得用于其他商业用途（如 [转卖]进行直接盈利或[编辑后售卖]进行间接盈利）。
2、本站所有内容均由合作方或网友上传，本站不对文档的完整性、权威性及其观点立场正确性做任何保证或承诺！文档内容仅供研究参考，付费前请自行鉴别。
3、如文档内容存在违规，或者侵犯商业秘密、侵犯著作权等，请点击“违规举报”。

碎片内容

华为三康(H3C)三层交换机VLAN配置实例

1 华为三康(H3C)三层交换机 VLAN配置实例 dis cu # sysname H3C # radius scheme system # domain system # acl number 2011 rule 0 deny rule 1 permit source 172

255 acl number 2012 rule 0 deny rule 1 permit source 172

255 acl number 2013 rule 0 deny rule 1 permit source 172

255 acl number 2021 rule 0 deny rule 1 permit source 172

255 acl number 2022 rule 0 deny rule 1 permit source 172

255 acl number 2023 rule 0 deny rule 1 permit source 172

255 acl number 2031 rule 0 deny rule 1 permit source 172

255 acl number 2032 rule 0 deny rule 1 permit source 172

255 acl number 2033 rule 0 deny rule 1 permit source 172

255 acl number 2041 rule 0 deny rule 1 permit source 172

255 ac
