题目:变频器在机床中的应用 学生:陈孝敏 学院: 安徽水利水电职业技术学院 班级:0 9 1 8 3 0 9 专业:机电设备维修与管理 指导老师: 蒋瑾瑾 摘要: 机床是工作母机的总称,包括车床,铣床,模床,冲床,刨床等,由于加工材质的不同,需要不同的转速,因此采用变频调速的机会很多,主轴传动结构一般采用交流电机和伺服电机,通过带传动把运动传给主轴,从而使主轴达到一定的转速,来完成切削加工。现在经济型数控机床中,一般使用变频器做为驱动部件。本文针对数控机床和普通机床改造中对主轴传动变频调速系统的应用需求,提出了采用罗克韦尔自动化的PowerFlex4型通用低压变频器的解决和实现方案。 关键词: 罗克韦尔自动化;低压变频器;数控机床;主轴;驱动 Abstract: Machine is the general term for machine tools, including lathes, milling machines, mold bed, presses, planer, etc., due to processing of different materials require different speeds, so many opportunities for use of frequency control, spindle structure commonly used AC motor drive and servo motor , the motion passed through the belt drive shaft, so that the spindle reaches a certain speed, to complete the cutting. Now that the economy CNC machine tools in general use the drive as the drive components. In this paper, general machine tools CNC machine tools and drive the transformation of the spindle frequency control system application requirements, the paper introduces Rockwell Automation's general-purpose low-voltage inverter PowerFlex4 solutions and implementations. Key words: Rockwell Automation; low frequency; NC machine tool; spindle; drive 引言: 数字控制机床,简称数控机床(NC , Numerical Control),是三十年来综合应用集机械、电气、液压、气动、微电子和信息等多项技术为一体的机电一体化产品,在现代机床生产中,一般采用多电机拖动,主轴和各进给系统分别由各自的电机来拖动。由于机床加工范围较广,不同的工件,不同的工序,使用不同的刀具,要求机床执行部件具有不同的运动速度,因此机床的主运动应能进行调速,主轴调速系统一般...
