安捷伦矢量信号分析工具说明书89601A

Agilent 89601A Vector Signal Analysis SoftwareTechnical Overview• Reach deeper into signals • Gather more data on signal problems• Gain greater insight On 1 March 2011, the 89601A softw are w as discontinued. Agilent w ill continue to support this product until 31 October 2013. The recommended replacement is the Agilent 89601B (89600 VSA softw are).2Table of ContentsOverview ..................................................................................................................................3Basic Vector Signal Analysis, Option 200 .........................................................................5Flexible Modulation Analysis, Option AYA ......................................................................20W-CDMA/HSPA (Enhanced HSPA) Modulation Analysis, Option B7U ....................21cdma2000/1xEV-DV, Option B7T ......................................................................................22TD-SCDMA Modulation Analysis, Option B7X...............................................................231xEV-DO Modulation Analysis, Option B7W ..................................................................243G-Modulation Analysis Bundle, Option B7N ................................................................24LTE FDD Modulation Analysis, Option BHD ...................................................................25LTE TDD Modulation Analysis, Option BHE ...................................................................25WLAN (IEEE 802.11a/b/g/) Analysis, Option B7R .......................................................27WLAN-HT (IEEE 802.11n) Analysis, Option B7Z ............................................................30Fixed WiMAX (IEEE-802.16-2004 OFDM) Modulation Analysis, Option B7S ...........33Mobile WiMAX (IEEE-802.16 OFDMA) Modulation Analysis, Option B7Y ...............36TETRA Enhanced...
