毕 业 论 文题 目 ZL100 轮式装载机的设计 摘 要本次设计主要进行装载机整体以与工作装置的设计,轮式装载机的工作装置由铲斗、连杆、摇臂、转斗油缸和举升油缸组成。依靠这套装置装载机可以对汽车、火车进行散料装载作业,也可以对散料进行短途运输作业、还可以进行平地修路等作业。由于轮式装载机常工作在各种复杂的工况下,这就要求轮式装载机具有良好的适应性和可靠性,尤其是工作装置的各种设计参数直接影响装载机的整机性能,因此对轮式装载机的设计提出了严格的要求。对轮式装载机工作装置的运动学、动力学进行讨论,以提高装载机作业效率,对轮式装载机的整机设计具有特别重要的意义。本次设计采纳新参数方法来设计铲斗尺寸参数,并验证容量;同时利用图解法设计连杆机构尺寸,并对连杆机构进行受力分析与强度校核。关键词:轮式装载机,工作装置,总体构造ABSTRACTWheel Loader from the bucket, connecting rod, rocker arm, boom, bucket cylinder and lift cylinder transfer form. The device loader can rely on buses and trains for bulk loading operations, bulk materials can also be short-distance transport operations, road repair, etc. can also be carried out ground operations. As the wheel loader often work in the complex condition, which requires wheel loader has a good adaptability and reliability, in particular, the installation of various design parameters directly affect the performance of the whole loader, Therefore, the design of the wheel loader made strict requirements. Wheel Loader on the kinematics, dynamics studies, to improve operating efficiency loader, wheel loader's machine on the design of particular importance. The design uses a new method to design parameters of the bucket size parameter, and verify that capacity; also use Graphic design size linkage, and linkage to conduct stress analysis and strength analysisKeywords: wheel loaders, work unit,the overall structure目 录摘 要 … … … … … … … … … … … … … … … … …...
