精制工段使用手册VIP免费

中国石油大连石化分公司350万吨/年重油催化裂化装置仿真系统使用手册（精制工段）北京东方仿真控制技术有限公司350万吨/年催化裂化装置仿真系统使用手册-1-目录一.工艺流程简介·············································································21．装置简介···················································································22．工艺流程说明·············································································2二.设备列表···················································································3三.仪表列表···················································································5四.装置主要现场阀列表···································································5五.操作规程···················································································95.1冷态开车···················································································95.2装置停车·················································································125.3事故处理·················································································14六.工艺卡片·················································································14七.项目列表·················································································14八.仿DCS系统流程图画面····························································15九.催化裂化装置精制工段仿真PI&D图············································16十.催化裂化装置精制工段仿真DCS图··············································24十一.催化裂化装置精制工段仿真现场图·············································28350万吨/年催化裂化装置仿真系统使用手册-2-一.工艺流程简介1．装置简介大连石化分公司3.5Mt/a重油催化裂化联合装置是公司“十五”工程期间的第一套装置，目的是满足全公司一、二次加工能力配套的要求，并与“十五”规划的总流程相匹配，把大连石化分公司建成原油加工能力为2000×104t/a的大型炼油基地。该装置建成后，大连石化分公司原油加工能力将达到1000×104t/a。该装置洛阳石化工程公司设计，中油一建和六建承建，是目前国内最大的催化裂化装置。装置从2001年11月破土动工，到2002年11月建成投产，仅历时一年时间，建设周期短，创国内催化装置建设之最。2002年11月18日，实现投料试车一次成功。装置在2003年10月1...
