建筑行业通用英文缩写及含义模板

常见的英语缩写 ( ABBREVIATIONS) 构件篇英语缩写中文翻译COLUMN柱子POST从梁上升起的柱子BASE PLATE底板CAP PLATE顶板COVER PLATE盖板END PLATE封板, 短板SEAL PLATE封板SHEAR PLATE剪切板CONNECTION PLATE连接板GIRDER主梁BEAM 梁/次梁SECONDARY BEAM次梁JOIST GIRDER主桁架JOIST次桁架BRACE支撑LINTEL过梁MISC杂件EMBED PALTE预埋板件ANCHOR BOLT地脚螺栓FRAME钢架RAILING扶手STAIR楼梯RC WALL混凝土墙BRACKET马仔PART/TYP PART零件ASSY组合件CANOPY雨棚CATWALK猫道LADDER爬梯PURLIN檩条FISH PLATE结合板HOIST BEAM起吊运输梁BUILT-UP SECTION组合截面BEARING PLATE支撑板CANTILEVER BEAM悬臂梁/挑梁CRANE GIRDER吊车梁CROSS BEAM井字梁GIRT抗风梁RING BEAM圈梁DIAPHRAGM横隔板STIFFENER/STIFF加劲板/肋GUSSET PLATE节点板HANGER 吊杆/吊环GRIP 夹具/卡子TIE BAR拉结钢筋TIE BEAM系梁TIE TOD系杆TIE ROD 系杆FLANGE翼缘/法兰WEB PLATE/WEB腹板图纸/版本篇DESIGN DRAWING设计图SHOP DRAWING施工图/详图FABRICATION DRAWING加工图ARCHITECTURE建筑图AS-BUILT DRAWING竣工图FOR APPROVAL审批FOR FAB 加工UPDATE 更新FOR FIELD USED现场使用材料篇SHS( SQUARE HOLLOW SECTION) 方通/方管RHS ( RECTANGLE HOLLOW SECTION) 矩形管CHS( CIRCULAR HOLLOW SECTION) 圆管/喉管GMS( GALV MILD STEEL) 低碳钢RSC( ROLLED STEEL CHANNEL) 槽钢RSA( ROLLED STEEL AMGLE) 角钢HSB ( HIGN STRENGTH BOLT) 高强螺栓TS( TUBE CHANNEL) 方通/方管 HSS( HOLLOW SQUARE SECTION) 方通/方管EA( EQUAL ANGLE) 等边角钢UA( UNEQUAL ANGLE) 不等边角钢UC( UNIVERSAL COLUMNS) 等边工字钢UB( UNIVERSAL BEAM) 不等边工字钢PFC( PARALLEL FLANGE CHANNEL) 方脚槽钢CSK BOLT沉头螺栓FLAT BAR扁钢CHANNEL槽钢ANGLE角钢TC BOLT扛剪型螺栓RB混凝土RIVET铆钉ROD圆钢PLATE板材SECTION STEEL型钢SHAPED STEEL型钢SEAMLESS STEEL PIPE无缝钢管( 圆) SEAMLESS STEEL TUBE无缝钢管( 方) WELDED STEEL PIPE焊接钢管( 圆) WELDED STEEL TUBE焊接钢管( 方) STEEL STRIP钢带/带钢STEEL BELT钢带/带钢STEEL WIRE钢丝GRATING格栅板焊接篇FIELD WELD现场焊接( 美) SITE WELD现场焊接( 英) SHOP WELD工厂焊接FILLET WELD角焊缝FPBW完全熔透对接焊BW对接...
