本科毕业设计(2012届)题目语音录放系统的设计学院专业班级学号学生姓名指导教师完成日期2012年5月诚信承诺我谨在此承诺:本人所写的毕业论文《语音录放系统的设计》均系本人独立完成,没有抄袭行为,凡涉及其他作者的观点和材料,均作了注释,若有不实,后果由本人承担。承诺人(签名):2012年5月22日摘要本论文主要实现语音录放系统的设计。语音录放系统主要包括单片机控制模块、语音采集模块、语音处理模块、信号放大模块,其中单片机控制模块是整个系统设计的关键。在语音的录放过程中,单片机通过SPI通信方式与语音模块进行通讯,来实现语音的录音与播放。由于每段录音都对应着不同的地址,因此在播放录音时,需要发送需要播放的地址即可播放。语音录放系统的信号处理过程主要包括语音的采集、信号的放大和语音的滤波。语音经过驻极体传感器,即麦克风,把声波信号转换成电信号。传感器采集的电信号进过放大电路,放大一定倍数,经滤波、耦合之后送至语音模块。语音模块对连续变化的语音信号进行采样,抽取其中的语音信号电平,直接存储在语音芯片ISD4004中,因此使得语音自然真实。当语音播放时,需要在语音芯片的输出段加一个带通滤波器,以滤除音频带宽以外的信号,从而减少杂音的干扰。STC89C52单片机的程序,使用keil编译程序进行设计和调试完成,其主要功能是控制语音模块,以及液晶显示模块。关键词:微控制器;录音放音;ISD4004;ABSTRACTThemainaimofthispaperistorealizethefunctionofvoicerecordingandplaybacksystem.Thekeytotheoverallsystemdesignofthevoicerecordingsystemwhichincludesasingle-chipcontrolmodule,voiceacquisitionmodule,voiceprocessingmodule,signalamplificationmodule,isMCUcontrolmodule.Inthevoiceplaybackprocess,themicrocontrollercommunicatesthroughSPIcommunicationvoicemodule,thusrealizingvoicerecordingandplayback.Eachrecordingcorrespondstoadifferentaddress,sothemicrocontrollerjustneedtosendtheaddressoftherecordingtobeplayedforplayback.Thesignalprocessingofthevoicerecordingsystemincludesspeechacquisition,signalamplificationandvoicefilter.Acousticsignalisconvertedintoelectricalsignalsthroughelectretssensor,whichisalsocalledmicrophone.Thesensorsignalswillbeamplifiedafterflowthroughtheamplifyingcircuit.Finallyitwillbesendtovoicemoduleafterfiltering,coupling.Continuousacousticsignalissampledbythevoicemodule,whichtakesoneofthevoicesignallevel,directlystoresitinthevoicechipISD4004,andmakesspeechnaturalandtrue.Whentherecordingisplayedweneedaband-passfilterinthevoicechipoutputsection,tofilteroutthesignaloutsidetheaudiobandwidththerebyreducingnoise.ThecodesoftheMicrocontrollerSTC89C52isdesignedandtestedbyusingkeilcompiler,whosemainfunctionistocontrolthevoicemoduleandLCDmodule.Keywords:Microprocessor;VoiceRecordingandplaying;ISD4004目录1引言...............................................................12概述..............................................................22.1语音录放系统概述.............................................22.2本设计方案的论证.............................................32.2.1系统的单片机选择论证....................................32.2.2系统的液晶选择..........................................32.2.3系统的滤波电路的选择....................................32.3研发方向和技术关键...........................................32.4主要技术指标.................................................33硬件设计............................................................53.1硬件的总体设计................................................53.2驻极体传声器..................................................53.3信号放大电路............................................
